150m HDMI Extender | HDMI Splitter With IR Remote | IR Passback Extender | Over Ethernet TCP IP by RJ45 Cat5 Cat5e Cat6

sold in last hours
Your Price:
$75.99 $88.18

22904181-eu-plug-china-1-tx
Quantity

Checkout Secure
Checkout Secure
Order in the next  to get it by

Viewing This Product



5 Great reasons to buy from us:

  • Image of Secure Ordering
  • Image of 365-Day Money-Back Guarantee
  • Image of 100% Satisfaction Guaranteed
  • Image of Easy Returns
  • Image of Free shipping (when you spend over XXX)

Item specifics:

Connector A: HDMI
Type: HDMI Cables
Packing: Carton Box
Gender: Female-Female
Application: DVD Player,Camera,Computer,Multimedia,TV BOX,Monitor,Television
Shielding: Non-Shielded
Connector B: HDMI
Package: Yes
Bundle: Bundle 1
Version: HDMI 1.4
Outer Diameter: HDMI Extender over TCP/IP with Audio Extractor
Model Number: HSV891 IR
Feature: None
Product Name: HDMI Extender over TCP/IP with Audio Extractor
Standard Power Inpu: 5V-12V adapter
HDMI Port: HDMI A type Female converter
Link Connection: UTP/STP CAT5/5e/6 hdmi to Rj45
Working Mode: Point to Point/mode Broadcast mode
3.5mm Audio Output Power: 60mW THD<0.1% SNR 110dB
Power Consumption: 3W(max)each hdmi extender 120m
Relative Humidity: 20% ~ 90% RH(Non-condensing)
Dimensions: 123x64x25mm HDMI Rj45 converter
Weight: 110g cascade receiver

Product Description:

TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e  Cat6 HDMI Extender Splitter IR Transmitter Receiver

​!!!      This product supports 1pcs of SENDER support maximum 253pcs of RECEIVER (over Swtich).

    If you want to buy more Receivers, please add the (HSV891-IR RX) item to the buy box(Cart) first, and then add the right number of (HSV891-IR RX) items to the buy box(Cart) again.

Introduction

This product not only can work as other normal HDMI extender by CAT5/6 cable up to maxim 150 meters, but also can transmit HDMI data over local network. The data could be transmitted over switch, router and other ethernet device, and extend the transfer distance to over 20km.
     It also could work in broadcast mode, like HDMI splitter, broadcast HDMI signal from one sender to multiple receivers.
     HSV891IR supports sending IR remote control signal from receiver side to sender side which could be used to control HDMI source devices.
     HSV891IR also integrate HDMI audio extractor that could extract stereo audio out from HDMI signal and output via 3.5mm jacket.
     HSV891IR have many professional designs which suitable for various application scenario, especially for engineering project usage. Such as 5V-12V wide range power supply, mountable aluminum alloy shielding.

Features

1. Signal enhance technology ensure 150meters transfer distance over CAT6 cable for 1080P FULL HD.

2. Powerful processing capability keep lower video latency < 150ms.

3. Extend transmit distance to 20Km over cascaded ethernet switch/router.

4. Broadcast mode transmit HDMI signal from one source to multiple receivers.

5. Sending IR signal from receiver side to sender side.

6. Integrated HDMI audio extractor output HDMI audio.

7. Supports 5V-12V wide range power supply.
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (3)

Specification

Power Supply: DC 5~12V/1A
IR Frequency Range:   20KHz~60KHz
Resolution Supported:  1080p@50Hz / 1080p@60Hz / 1080p@24Hz
      1080i@50Hz / 1080i@60Hz   720p@50Hz / 720p@60Hz /   576i@50Hz / 480p@60Hz
Working Temperature:   -10°C ~ 60°C
Link Connection:   UTP/STP CAT5/5e/6
3.5mm Audio Output:    60mW THD<0.1% SNR 110dB
Power Consumption:   3W(max)each
Working Mode:
                       *Point to Point mode
                       *Broadcast mode( Point to MultiPoint)
                       *Cascade mode
Transfer Distance:
                       Point to Point Mode:
                       CAT5  100meters
                       CAT5e 120meters
                       CAT6  150meters

Cascade Mode:
                      20Km maximum
Relative Humidity :20% ~ 90% RH(Non-condensing)
Dimensions :123x64x25mm
Weight :110g each
891IR-5 - EN
891IR-4 - EN
891IR-3 - EN
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (13)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (1)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (4)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (5)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (7)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (9)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (10)
TX RX HDMI Extender with IR Remote over ethernet TCP IP by RJ45 Cat5 Cat5e Cat6 HDMI Extender Splitter IR Transmitter Receiver (12)
Packaging Details
  • Unit Type: piece
  • Package Weight: 0.34kg (0.75lb.)
  • Package Size: 20cm x 10cm x 5cm (7.87in x 3.94in x 1.97in)
